PRO’SKIT TRUE-RMS DIGITAL MULTIMETER | MT1236

FEATURES
——–
• PRO’SKIT TRUE-RMS Digital Multimeter MT-1236
• -Full function
• -Accurate value
• -ACV ACA true RMS measurement
• -Overload protection
• Full function
• For ACA, ACV, DCA, DCV, frequency, duty cycle, diode test and more
• Accurate value
• W/ACV ACA true RMS measurment
• Overload protection
• Ensures user safety
• Item #:MT-1236 true RMS digital multimeter
• LCD Display :3 5/6 5999 counts
• DCV: 600mv/6V/60V/600V ±(0.8% + 5D)
• ACV: 600mv/6V/60V/600V ±(1% + 4D) TRUE-RMS
• DCA: 60ma/600mA ±(1.2% + 5 D), 10a ±(3.0% + 5D)
• ACA: 60ma/600mA ±(1.5% + 5 D), 10a ±(3.0% + 5D) TRUE-RMS
• Frequency :9.999Hz/99.99Hz/999.9Hz/9.999kHz/99.99kHz/999.9kHz/9.999MHz ±(1.2% + 5D)
• Duty cycle: 1% ~ 99% ±(2.5% + 5 D)
• Temperature:
• -20 ~ 1300 ℃ ±(1.0% + 3D)
• -4℉ ~ 2372 ℉ ±(0.5% + 2D)
• ResistanceΩ :600Ω/6K/600K/6M/60mΩ ±(0.8% + 5D), 100mf ±(4% + 10D)
• Capacitance: 60nf/600nf/6UF/60UF/600UF/6mf ±(4% + 5D)
• Temperature(℃/℉):
• -20℃ ~ 1000 ℃ ±(1% + 3D)
• -4℉ ~ 2372 ℉ ±(1% + 3D)
• Buzzer continuity: ≤ 30Ω , buzzer beeps
• Diode test: Y
• NCV detection: Y
• Data hold; Y
• LED light: Y
• LCD backlight: Y
• Analog bar: Y
• Low battery indication: Y
• Accessories:Test lead, K-type thermocouple, manual
• Power :1.5V AAA x 3PCs
• Dimension :148mm x 79mm x 48mm
• Weight :210g(without battery)
