ROTATION LASER | GRL 300 HV
Green laser line: up to four times better visibility than a red line
• Green laser line: up to four times better visibility than a red line
• Easy to set up in both the horizontal and vertical modes due to automatic self-leveling of 8% (± 5°)
• The shock warning function, which can be switched on and off, prevents leveling errors in the event of shocks or vibrations
Description
FEATURES
——–
• Green laser line: up to four times better visibility than a red line
• Easy to set up in both the horizontal and vertical modes due to automatic self-leveling of 8% (± 5°)
• The shock warning function, which can be switched on and off, prevents leveling errors in the event of shocks or vibrations
THIS PRODUCT INCLUDES
———————
• Laser receiver LR 1G Professional 0 601 069 700
• Holder also available separately as an accessory (spare part number 1 608 M00 05A)
• Remote control RC1 Professional 0 601 069 900
• Universal mount WM 4 Professional 0 601 092 400
• Battery compartment (spare part number 1 608 M00 05D)
• Laser target (blue) (spare part number 1 608 M00 05K)
• Laser viewing glasses (green) (spare part number 1 608 M00 05J)
• 1 x 9 V block battery (6LR61)
• 2 x 1.5 V LR20 battery (D)
• 1 x 1.5 V LR6 battery (AA)
• Carrying case (spare part number 1 608 M00 05F)
TECHNICAL DATA
————–
• Working range with the receiver, value: 300 m
• Accuracy: ± 3.0 mm at 30 m* (*plus use-dependent deviation)
• Laser diode: 532 nm, < 5 mW
• Operating temperature: 0 – 40 °C
• Storage temperature: -20 – 70 °C
• Laser class: 3R
• Working range: 100 m
• Working range with receiver: 300 m (Diameter)
• Working range without receiver: 100 m (Diameter)
• Self-leveling range: ± 5° (8%)
• Leveling time: 15 s
• Dust and splash protection: IP 54
• Rotation speed: 150, 300, 600 rpm
• Power supply: NiMH battery pack, 2 x 1.5 V LR20 (D)
• Tripod thread: 5/8"
• Weight, approx.: 1.8 kg
• Colour of laser line: green
• Compatible laser receivers: LR 1G
• Slope function: no
• Working range, value: 100 m
