FLUKE 717-1G PRESSURE CALIBRATOR

The
Fluke 717-1G Pressure Calibrator
is designed for professionals requiring accurate pressure and current measurements in various applications. This calibrator measures pressure from -1 to 1 psi (-68.9 to 68.9 mbar) with an internal sensor, achieving 0.05% full-scale accuracy. It also measures current (mA) with 0.015% accuracy and 0.001 mA resolution, while providing a 24V loop power supply. The device features a push-button interface for easy operation, is EMI tolerant, dust and splash resistant, and includes a removable battery door for quick battery changes. Additionally, it supports pressure switch testing and allows selection among eleven different engineering units.
Key Features:
Specifications:
The
Fluke 717-1G Pressure Calibrator
is designed for professionals requiring accurate pressure and current measurements in various applications. This calibrator measures pressure from -1 to 1 psi (-68.9 to 68.9 mbar) with an internal sensor, achieving 0.05% full-scale accuracy. It also measures current (mA) with 0.015% accuracy and 0.001 mA resolution, while providing a 24V loop power supply. The device features a push-button interface for easy operation, is EMI tolerant, dust and splash resistant, and includes a removable battery door for quick battery changes. Additionally, it supports pressure switch testing and allows selection among eleven different engineering units.
Key Features:
Specifications:

• Measures pressure from -1 to 1 psi (-68.9 to 68.9 mbar) with 0.05% full-scale accuracy.
• Measures current (mA) with 0.015% accuracy and 0.001 mA resolution.
• Provides 24V loop power supply.
• Compact and lightweight design for easy portability.
• EMI tolerant, dust and splash resistant.
• Removable battery door for quick battery changes.
• Compatible with non-corrosive gases and liquids.
• Pressure switch test function captures set, reset, and deadband values.
• Selectable engineering units: psi, kPa, bar, mbar, inH?O, cmH?O, kg/cm², mmHg, inHg.

Specification | Details
———————–
Pressure Measurement Range | -1 to 1 psi (-68.9 to 68.9 mbar)
Pressure Accuracy | 0.05% of full scale
Current Measurement Range | 0 to 24 mA
Current Accuracy | 0.015% of reading ± 0.001 mA
Pressure Connection | 1/8 NPT female
Display | Backlit LCD
Power Supply | One 9V alkaline battery
Battery Life | Approximately 18 hours
Dimensions | 201 mm x 98 mm x 52 mm
Weight | 600 g
Operating Temperature | -10°C to 55°C
Humidity | 10% to 95% non-condensing
Included Accessories | Test leads, alligator clips, user manual, soft carrying case
