FLUKE GAUGE PRESSURE MODULE | 700P06EX

The Fluke 700P06Ex is a high-precision gauge pressure module engineered for use in hazardous environments. It allows professionals to measure pressure with high accuracy, displaying readings in 10 different units as specified in the calibrator setup. The module features internal temperature compensation from 0°C to 50°C, ensuring consistent performance across a range of conditions. Its rugged urethane-molded case provides protection against rough handling and harsh environments. Certified for intrinsic safety, the 700P06Ex is suitable for use in areas where explosive gases may be present.
Key Features:
Specifications:
The Fluke 700P06Ex is a high-precision gauge pressure module engineered for use in hazardous environments. It allows professionals to measure pressure with high accuracy, displaying readings in 10 different units as specified in the calibrator setup. The module features internal temperature compensation from 0°C to 50°C, ensuring consistent performance across a range of conditions. Its rugged urethane-molded case provides protection against rough handling and harsh environments. Certified for intrinsic safety, the 700P06Ex is suitable for use in areas where explosive gases may be present.
Key Features:
Specifications:

• Pressure Range:0 to 100 psi (0 to 690 kPa)
• Resolution:0.01 psi
• Reference Uncertainty:±0.025% of full scale
• Total Uncertainty (1 year):±0.05% of full scale
• Temperature Compensation:0°C to 50°C
• Media Compatibility:Fluids compatible with 316 stainless steel
• Safety Certifications:CSA: I.S. Class I, Div 1, Groups A-D T4, Ta = 0°C to 50°C; ATEX II 1G EEx ia IIC T4
• Rugged Design:Urethane-molded case for enhanced durability
• Calibration:Includes NIST-traceable calibration certificate; can be calibrated locally using the Fluke 700PCK Pressure Calibration Kit

Specification | Details
———————–
Pressure Range | 0 to 100 psi (0 to 690 kPa)
Resolution | 0.01 psi
Reference Uncertainty | ±0.025% of full scale
Total Uncertainty (1 year) | ±0.05% of full scale
Temperature Compensation | 0°C to 50°C
Media Compatibility | Fluids compatible with 316 stainless steel
Safety Certifications | CSA: I.S. Class I, Div 1, Groups A-D T4, Ta = 0°C to 50°C; ATEX II 1G EEx ia IIC T4
Dimensions | 5.24 in x 2.6 in x 1.38 in (133 mm x 66 mm x 35 mm)
Weight | 10.5 oz (300 g)
