FLUKE PRESSURE TEST GAUGE 690 BAR | 700RG31

The Fluke 700RG31 Pressure Test Gauge offers reliable and accurate pressure measurements in the range of -14 to 10,000 PSI (up to 690 Bar). This rugged gauge is ideal for both field and laboratory calibration tasks. It features a large digital display with a 20-segment bar graph for easy readings. The gauge is CSA and ATEX certified, making it safe for use in hazardous environments. Its robust design ensures long-lasting performance in demanding industrial conditions.
Key Features:
Specifications:
The Fluke 700RG31 Pressure Test Gauge offers reliable and accurate pressure measurements in the range of -14 to 10,000 PSI (up to 690 Bar). This rugged gauge is ideal for both field and laboratory calibration tasks. It features a large digital display with a 20-segment bar graph for easy readings. The gauge is CSA and ATEX certified, making it safe for use in hazardous environments. Its robust design ensures long-lasting performance in demanding industrial conditions.

KEY FEATURES:
————-

SPECIFICATIONS:
—————

• Pressure Range:-14 to 10,000 PSI (-0.97 to 690 Bar)
• High Accuracy:±0.05% FS for positive pressure; ±0.1% FS for vacuum
• Rugged Design:Built for industrial and laboratory environments
• Digital Display:5½-digit display with 20-segment bar graph
• Battery Life:Up to 2000 hours on slow sample rate

Specification | Details
———————–
Range | -14 to 10,000 PSI (-0.97 to 690 Bar)
Resolution | 1 PSI (0.01 Bar)
Accuracy | ±0.05% FS (positive), ±0.1% FS (vacuum)
Burst Pressure | 20,000 PSI (1,035 Bar)
Pressure Connection | ¼” NPT male
Display | 5½ digits, 0.65-inch display, 20-segment bar graph
Power Supply | 3 x AA alkaline batteries
Battery Life | Up to 2000 hours
Dimensions | 5 x 4.5 x 1.5 in (12.7 x 11.4 x 3.7 cm)
Weight | 0.5 kg
