DIGITAL MULTIMETER

Features:
Basic measurements:
Additional measurements:
Measurement accuracy:
An example of determining the accuracy for the measurement of ac voltage. Calculation for the measurement result: 235v
Additional information:
Technical data:

FEATURES:
———
Basic measurements:
Additional measurements:
Measurement accuracy:
An example of determining the accuracy for the measurement of ac voltage. Calculation for the measurement result: 235v
Additional information:

TECHNICAL DATA:
—————

• The universal meter yt-73080 with a manual range for each measurement allows you to perform basic and advanced electrical measurements.
• This is the basic model in our offer.
• Additional protection against mechanical damage is the so-called holster – a rubber housing that is pulled over the housing of the device.
• Alternating voltage measurement: ac 0-500v
• Dc voltage measurement: dc 0-500v
• Dc current measurement: dc 0-5a
• Resistance measurement: 0-2m
• Diode test: I f 1ma, u r 3v
• Continuity test: 0-30
• Hfe transistor test: 0-1000, built-in test socket
• Square wave generator: 5vpp, 50hz
• The accuracy of the measurement of the yt-73080 meter for this range is: ± (2% + 10), resolution 1v
• Calculation of measurement error formula: (measurement result x 2%) + 10 x resolution
• Calculations: (235 x 2%) + 10 x 1 = 4.7 + 10 = 14.7v
• Lcd display, the maximum displayed result: 1999
• Acoustic signal in the circuit continuity test for resistance below 30?
• Measuring probes included
• Construction with overload protection
• Housing made of abs plastic + the so-called holster, I.E. A rubber casing that protects the meter against mechanical damage
• Low battery indicator
