FLUKE I400S AC CURRENT CLAMP

The
Fluke i400s AC Current Clamp
is an essential accessory for professionals seeking to enhance their oscilloscopes or power quality meters’ functionality. This clamp enables
safe and accurate AC current measurements up to 400 amperes
without the need to interrupt the circuit, ensuring both efficiency and safety in various electrical applications.
Key features include:
Specifications:
The
Fluke i400s AC Current Clamp
is an essential accessory for professionals seeking to enhance their oscilloscopes or power quality meters’ functionality. This clamp enables
safe and accurate AC current measurements up to 400 amperes
without the need to interrupt the circuit, ensuring both efficiency and safety in various electrical applications.
Key features include:
Specifications:

• Compact Design:Specially designed to offer maximum utility in a compact shape, making it convenient for use in tight spaces.
• Non-Intrusive Measurement:Allows for accurate current readings without breaking the circuit, enhancing safety and convenience during measurements.

Feature | Specification
———————–
AC Current Range | 0.5 A to 40 A AC (40 A range); 5 A to 400 A AC (400 A range)
Output Sensitivity | 10 mV/A (40 A range); 1 mV/A (400 A range)
Safety Rating | CAT IV 600 V / CAT III 1000 V
Maximum Conductor Size | Ø 32 mm
Output Connection | BNC connector; optional BNC-to-banana adapter available for DMMs
Compatibility | Works with oscilloscopes and power quality meters; compatible with DMMs using optional adapter
Dimensions | 150 mm x 70 mm x 30 mm
Weight | 0.5 kg (1.1 lbs)
