FLUKE 1663 MULTIFUNCTION INSTALLATION TESTER

The
Fluke 1663 Multifunction Installation Tester
offers comprehensive testing capabilities for electrical installations in domestic, commercial, and industrial settings. Combining advanced measurement functions with user-friendly operation, it ensures that fixed wiring is safe and correctly installed, meeting IEC 60364 and all relevant local standards. Its compact and lightweight design, along with a padded carrying and waist strap, provides convenience for professionals during testing procedures.
Key Features:
Technical Specifications:
The
Fluke 1663 Multifunction Installation Tester
offers comprehensive testing capabilities for electrical installations in domestic, commercial, and industrial settings. Combining advanced measurement functions with user-friendly operation, it ensures that fixed wiring is safe and correctly installed, meeting IEC 60364 and all relevant local standards. Its compact and lightweight design, along with a padded carrying and waist strap, provides convenience for professionals during testing procedures.

KEY FEATURES:
————-

TECHNICAL SPECIFICATIONS:
————————-

Key Features

• Continuity Testing:Performs continuity tests at L-N and N-PE inputs to verify proper wiring connections.
• RCD Testing:Tests smooth DC sensitive Residual Current Devices (RCDs) of Type B, ensuring their correct operation.
• Earth Resistance Measurement:Measures earth resistance to assess the effectiveness of grounding systems.
• Voltage and Frequency Measurement:Accurately measures voltage and frequency to ensure electrical systems operate within specified parameters.
• Wiring Polarity Checker:Detects broken N wires to ensure correct wiring and enhance safety.
• Insulation Resistance Measurement:Measures insulation resistance to verify the integrity of wiring insulation.
• Loop and Line Resistance Measurement:Assesses loop and line resistance to ensure proper circuit functionality.
• Automatic RCD Test Sequence:Provides an automatic sequence for RCD testing, streamlining the process.
• Phase Sequence Indicator:Indicates the phase sequence to ensure correct phase installation.
• On/Off Switchable Auto-Start for RCD and Loop Test:Enhances efficiency by automatically starting tests when conditions are met.
• Self-Test Function:Conducts a self-test to verify proper operation, providing additional user confidence.
• Illuminated Display:Features a backlit display for clear visibility in various lighting conditions.
• Memory Interface:Includes a memory interface for storing test results, facilitating data management.

Specifications

Specification | Details
———————–
AC Voltage Measurement | Up to 500 V
Frequency Measurement | 45 Hz to 65 Hz
Insulation Test Voltages | 50 V, 100 V, 250 V, 500 V, 1000 V
Insulation Resistance Range | Up to 1000 M?
Loop and Line Resistance Measurement | 0.01 ? to 2000 ?
Continuity Test Current | 200 mA
RCD Test Currents | 10 mA, 30 mA, 100 mA, 300 mA, 500 mA, 1000 mA
Dimensions | 25 cm x 12.5 cm x 10 cm
Weight | 1.3 kg (including batteries)
Power Supply | Six AA batteries
