FLUKE 717-10000G PRESSURE CALIBRATOR

The
Fluke 717-10000G Pressure Calibrator
is a compact, lightweight, and user-friendly device designed for professionals requiring precise pressure calibration. It measures pressure up to 10,000 psi (690 bar) with an internal sensor and offers 0.05% full-scale accuracy. Additionally, it measures current (mA) with 0.015% accuracy and 0.001 mA resolution while providing a 24V loop power supply. The calibrator features a push-button interface for easy operation, is EMI tolerant, dust and splash resistant, and includes a removable battery door for quick battery changes. It also supports pressure switch testing and allows for the selection of eleven different engineering units.
fluke.com
Key Features:
Specifications:
The
Fluke 717-10000G Pressure Calibrator
is a compact, lightweight, and user-friendly device designed for professionals requiring precise pressure calibration. It measures pressure up to 10,000 psi (690 bar) with an internal sensor and offers 0.05% full-scale accuracy. Additionally, it measures current (mA) with 0.015% accuracy and 0.001 mA resolution while providing a 24V loop power supply. The calibrator features a push-button interface for easy operation, is EMI tolerant, dust and splash resistant, and includes a removable battery door for quick battery changes. It also supports pressure switch testing and allows for the selection of eleven different engineering units.
fluke.com
Key Features:
Specifications:

• Measures pressure up to 10,000 psi (690 bar) with 0.05% full-scale accuracy.
• Measures current (mA) with 0.015% accuracy and 0.001 mA resolution.
• Provides 24V loop power supply.
• Compact and lightweight design for easy portability.
• EMI tolerant, dust and splash resistant.
• Removable battery door for quick battery changes.
• Compatible with non-corrosive gases and liquids.
• Pressure switch test function captures set, reset, and deadband values.
• Selectable engineering units: psi, kPa, bar, mbar, inH?O, cmH?O, kg/cm², mmHg, inHg.

Specification | Details
———————–
Pressure Measurement Range | 0 to 10,000 psi (0 to 690 bar)
Pressure Accuracy | 0.05% of full scale
Current Measurement Range | 0 to 24 mA
Current Accuracy | 0.015% of reading ± 0.001 mA
Pressure Connection | 1/8 NPT female
Display | Backlit LCD
Power Supply | One 9V alkaline battery
Battery Life | Approximately 18 hours
Dimensions | 201 mm x 98 mm x 52 mm
Weight | 600 g
Operating Temperature | -10°C to 55°C
Humidity | 10% to 95% non-condensing
Included Accessories | Test leads, alligator clips, user manual, soft carrying case
