FLUKE 724 TEMPERATURE CALIBRATOR

The Fluke 724 is a versatile and user-friendly temperature calibrator designed for professionals who need to measure and source a wide range of temperature-related parameters. It can measure and source 10 types of thermocouples and 7 types of RTDs, in addition to voltage and resistance. The calibrator also supports DC current (mA) measurement with loop power for transmitters.
Featuring a dual display, the Fluke 724 allows for simultaneous viewing of input and output signals, simplifying the calibration process. Its straightforward interface eliminates complex menus, enabling quick and efficient testing. It includes features such as 25% and 100% step functions for rapid linearity tests, as well as auto-ramp and auto-step capabilities for remote testing. The rugged, compact design with a backlit display makes it suitable for use in low-light environments.
Specifications Table:
Features:
The Fluke 724 is a versatile and user-friendly temperature calibrator designed for professionals who need to measure and source a wide range of temperature-related parameters. It can measure and source 10 types of thermocouples and 7 types of RTDs, in addition to voltage and resistance. The calibrator also supports DC current (mA) measurement with loop power for transmitters.
Featuring a dual display, the Fluke 724 allows for simultaneous viewing of input and output signals, simplifying the calibration process. Its straightforward interface eliminates complex menus, enabling quick and efficient testing. It includes features such as 25% and 100% step functions for rapid linearity tests, as well as auto-ramp and auto-step capabilities for remote testing. The rugged, compact design with a backlit display makes it suitable for use in low-light environments.

SPECIFICATIONS TABLE:
———————

FEATURES:
———

• Measures and sources 10 types of thermocouples and 7 types of RTDs.
• Dual display for simultaneous viewing of input and output parameters.
• Measures and sources voltage and resistance, with mA measurement capability.
• Provides 24V loop power to operate transmitters during testing.
• Simple, user-friendly interface with no complex menus.
• Step and ramp functions for quick linearity tests and remote operations.
• Rugged, compact design suitable for field use.
• Backlit display for easy operation in low-light environments.

Specification | Details
———————–
Measurement Functions | Thermocouples, RTDs, Resistance (?), Voltage (V), DC Current (mA)
Source Functions | Thermocouples, RTDs, Resistance (?), Voltage (V)
Supported Thermocouple Types | J, K, T, E, R, S, B, L, U, N, XK, BP
Supported RTD Types | NI-120, PT-100 (385), PT-100 (393), PT-100 (JIS), PT-200 (385), PT-500 (385), PT-1000 (385)
Voltage Measurement Range | 0 to 30 V DC
Current Measurement Range | 0 to 24 mA DC
Resistance Measurement Range | 0 to 4000 ?
Power Supply | Four AA batteries
Battery Life | Approximately 25 hours of typical use
Dimensions | 130 × 236 × 61 mm
Weight | 1 kg
Operating Temperature | -10 to 55 °C
Safety Rating | CAT II 30 V
